Unbleached Muslin Frame
Professional Unbleached Muslin Frame. Built with a precision-welded 304 stainless steel wire frame and solid 3/8" mounting pin. Provides positive grip in 2-1/2" gobo heads to cut spill, control lens flare, and shape cinema lighting beams with razor-sharp shadow edges.
SKU:
LFC-1824M-U00
Unbleached Muslin Frame
Engineering Fact Sheet & Technical Specifications
Dimensional & Mechanical Metrics Imperial / Metric
| Component Specification | Cinema Flag / Cutter |
| Mounting / Pin Interface | 1-1/8" Junior Pin / 5/8" Baby Pin |
| Structural Material | 304 Stainless Steel Frame Rod |
| Hardware Fastener Grade | Heavy-Duty Polyester Edge Binding & Industrial Hook-and-Loop Fasteners |
| Corrosion Protection | Corrosion-Resistant Stainless Steel Frame / NFPA 701 Fire Retardant Fabric |
Engineering & Rigging Tolerances Hollywood Stage Standards
| Precision Machining Tolerance | Β±0.005" CNC Tolerances |
| Lockup Mechanism | Captive Steel T-Handle / Set Bolt |
| Anti-Galling Protection | CDA 360 Solid Brass Bushing |
| Working Load Limit (WLL) | Certified Cinema Rigging Capacity |
| Rigging Safety Factor | 5:1 ASME B30.26 Standard |
Cinema Rigging Physics & Fluid Drag Aerodynamics
Hollywood Safety ProtocolsRayleigh Fluid Drag Aerodynamics
F_drag = 1/2 Ο vΒ² Cd AUnder standard atmospheric conditions (Ο = 1.225 kg/mΒ³), sustained 20 mph (8.94 m/s) wind generates approximately 7.4 lbs (33 N) of lateral drag force against this Cinema Flag / Cutter surface area (Cd β 1.20).
3-Point 120Β° Guy-Wire Anchor Protocol
120Β° RADIAL ANCHORINGTo counteract overturning moments (M_overturn = F_drag Γ h), outdoor overhead frames must be stabilized with high-tensile guy-lines positioned at 120Β° radial angles and 45Β° ground elevation anchored to 30" earth augers or 100+ lb ballast blocks.
Stand Base Ballast & Safety Factors
ASME 5:1 SAFETY FACTORAlways place a minimum of 3Γ 25 lb (75 lbs) to 4Γ 35 lb (140 lbs) saddle sandbags or shotbags on each supporting stand's high leg. Maintain strict compliance with ASME B30.26 cinema rigging safety standards.
Complete Your Grip & Lighting Control Package
Features standard 3/8" and 5/8" solid stainless pins. Compatible with Norms 2-1/2" Gobo Heads, Master C-Stands, and Baby Walker Stands.
Standard Hardware Lifetime (Frame) / Limited (Textile)
All Norms cinema grip hardware and frame components are built in Sun Valley, CA and backed by our legendary warranty against manufacturing defects.
Product Info
| Size | 18" x 24" or 24" x 36" or 36" x 36" or 42" x 42" or 48" x 48" |
