Black Double Net Dot
Engineering Fact Sheet & Technical Specifications
Dimensional & Mechanical Metrics Imperial / Metric
| Component Specification | Precision Dot / Finger Scrim |
| Mounting / Pin Interface | 1-1/8" Junior Pin / 5/8" Baby Pin |
| Structural Material | 304 Stainless Steel Frame Rod |
| Hardware Fastener Grade | Heavy-Duty Polyester Edge Binding & Industrial Hook-and-Loop Fasteners |
| Corrosion Protection | Corrosion-Resistant Stainless Steel Frame / NFPA 701 Fire Retardant Fabric |
Engineering & Rigging Tolerances Hollywood Stage Standards
| Precision Machining Tolerance | ยฑ0.005" CNC Tolerances |
| Lockup Mechanism | Captive Steel T-Handle / Set Bolt |
| Anti-Galling Protection | CDA 360 Solid Brass Bushing |
| Working Load Limit (WLL) | Certified Cinema Rigging Capacity |
| Rigging Safety Factor | 5:1 ASME B30.26 Standard |
Cinema Rigging Physics & Fluid Drag Aerodynamics
Hollywood Safety ProtocolsRayleigh Fluid Drag Aerodynamics
F_drag = 1/2 ฯ vยฒ Cd AUnder standard atmospheric conditions (ฯ = 1.225 kg/mยณ), sustained 20 mph (8.94 m/s) wind generates approximately 0.7 lbs (3 N) of lateral drag force against this Precision Dot / Finger Scrim surface area (Cd โ 1.20).
3-Point 120ยฐ Guy-Wire Anchor Protocol
120ยฐ RADIAL ANCHORINGTo counteract overturning moments (M_overturn = F_drag ร h), outdoor overhead frames must be stabilized with high-tensile guy-lines positioned at 120ยฐ radial angles and 45ยฐ ground elevation anchored to 30" earth augers or 100+ lb ballast blocks.
Stand Base Ballast & Safety Factors
ASME 5:1 SAFETY FACTORAlways place a minimum of 3ร 25 lb (75 lbs) to 4ร 35 lb (140 lbs) saddle sandbags or shotbags on each supporting stand's high leg. Maintain strict compliance with ASME B30.26 cinema rigging safety standards.
Complete Your Grip & Lighting Control Package
Features standard 3/8" and 5/8" solid stainless pins. Compatible with Norms 2-1/2" Gobo Heads, Master C-Stands, and Baby Walker Stands.
Standard Hardware Lifetime (Frame) / Limited (Textile)
All Norms cinema grip hardware and frame components are built in Sun Valley, CA and backed by our legendary warranty against manufacturing defects.
Product Info
| Size | 6" or 3" or 9" |
