Frame Hardware Bag
Heavy-duty Frame Hardware Bag built from 1000D ballistic Cordura nylon. Designed to store, organize, and transport overhead and butterfly frame corners, ears, splices, scrims, and rigging clamps. Features dual reinforced handles and high-density foam padding for maximum on-set durability.
SKU:
FBA-0V000-L00
Frame Hardware Bag
Engineering Fact Sheet & Technical Specifications
Dimensional & Mechanical Metrics Imperial / Metric
| Component Specification | 12' x 12' |
| Mounting / Pin Interface | 1-1/8" Junior Pin / 5/8" Baby Pin |
| Structural Material | 1000D Ballistic Cordura Nylon |
| Hardware Fastener Grade | Reinforced Box-X Stitching with Heavy-Duty Steel D-Rings |
| Corrosion Protection | Weather-Resistant DWR Water-Repellent Coating |
Engineering & Rigging Tolerances Hollywood Stage Standards
| Precision Machining Tolerance | ยฑ0.005" CNC Tolerances |
| Lockup Mechanism | Captive Steel T-Handle / Set Bolt |
| Anti-Galling Protection | CDA 360 Solid Brass Bushing |
| Working Load Limit (WLL) | Certified Cinema Rigging Capacity |
| Rigging Safety Factor | 5:1 ASME B30.26 Standard |
Cinema Rigging Physics & Fluid Drag Aerodynamics
Hollywood Safety ProtocolsRayleigh Fluid Drag Aerodynamics
F_drag = 1/2 ฯ vยฒ Cd AUnder standard atmospheric conditions (ฯ = 1.225 kg/mยณ), sustained 20 mph (8.94 m/s) wind generates approximately 176.7 lbs (786 N) of lateral drag force against this 12' x 12' surface area (Cd โ 1.20).
3-Point 120ยฐ Guy-Wire Anchor Protocol
120ยฐ RADIAL ANCHORINGTo counteract overturning moments (M_overturn = F_drag ร h), outdoor overhead frames must be stabilized with high-tensile guy-lines positioned at 120ยฐ radial angles and 45ยฐ ground elevation anchored to 30" earth augers or 100+ lb ballast blocks.
Stand Base Ballast & Safety Factors
ASME 5:1 SAFETY FACTORAlways place a minimum of 3ร 25 lb (75 lbs) to 4ร 35 lb (140 lbs) saddle sandbags or shotbags on each supporting stand's high leg. Maintain strict compliance with ASME B30.26 cinema rigging safety standards.
Complete Your Studio Rigging Package
Designed for seamless integration with Norms Grip Heads, Hardware Clamps, and Cordura Ballast Sandbags.
Limited Textile Warranty (3-Year Heavy Commercial)
All Norms cinema grip hardware and frame components are built in Sun Valley, CA and backed by our legendary warranty against manufacturing defects.
Product Info
| Size | Small or Medium or Large |
