C-Stand Boom Arm with Dual Grip Head Fulcrum (40" Extension)
SKU:
BAB-CZXES-000
C-Stand Boom Arm with Dual Grip Head Fulcrum (40" Extension)
Engineering Fact Sheet & Mechanical Specifications
Elevation & Weight Metrics Imperial / Metric
| Maximum Height | 10' 4" (316.2 cm) |
| Minimum Height | 4' 2" (127 cm) |
| Total Stand Weight | 17 lbs (7.8 kg) |
| Base Footprint Diameter | 2' 5" (73.7 cm) |
| Working Load Limit (WLL) | 30.0 lbs (13.6 kg) Direct Vertical / 10.0 lbs (4.5 kg) at Full Horizontal Arm Extension |
Mechanical Architecture Hardware Standards
| Floor Clearance | 1.5" (3.8 cm) |
| Folded Dimensions | 4' 2" H Γ 1' 7" W |
| Riser Column Sections | 2 Telescoping Sections |
| Head / Mounting Interface | 5/8" Baby Pin |
| Base & Leg Architecture | Sliding Leg |
| Leveling Leg (Rocky Mtn) | Yes |
40" C-Stand Cinema Rigging Physics & Mechanical Safety
Hollywood Stage ProtocolsDual Mechanical Load Ratings
30 LBS VERT / 10 LBS ARMWhen mounting luminaires directly onto the top 5/8" Baby Pin, the stand supports its full 30.0 lbs (13.6 kg) direct vertical WLL. When extending a 40" gobo arm horizontally, payload capacity decreases to 10.0 lbs (4.5 kg) due to rotational torque (Ο = r Γ F β€ 45 NΒ·m / 33.2 ft-lbs) on the 2.5" grip head knuckle.
The Right-Hand Rule of Rigging Safety
CLOCKWISE GRAVITY LOCKAlways orient extension arms and modifiers so load gravity acts clockwise relative to the T-handle knob. Downward weight actively self-tightens the knuckle brake pads; mounting in reverse allows gravity to loosen the T-handle and causes catastrophic fixture slippage.
High-Leg Ballast & Moment Stabilization
MOMENT COUNTERWEIGHTINGCentury stand stepped bases feature offset planar legs. The High Leg provides the primary stabilizing lever arm. Always orient the high leg directly in the direction of the cantilevered load and secure it with a minimum 25 lb (11.3 kg) saddle sandbag to prevent stand tipping.
Complete Your C-Stand Rigging Package
Engineered to integrate seamlessly with Norms 2-1/2" Gobo Heads, Stainless Steel Grip Extension Arms, Spring Clamps, and Cordura Saddle Sandbags.
First-Ever Full Lifetime Warranty on Grip Stands
All Norms grip stands are backed by a complete lifetime warranty against manufacturing defects.
